Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks such as streaming video, playing music, and encoding media are handled by the processor's Efficient-cores.
The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 32 threads are assigned to the right core at the right time.
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Intel Thermal Velocity Boost (TVB) is a technology that unlocks extra CPU performance by pushing the maximum frequency to 5.8 GHz when thermal headroom and turbo power budget are available. It is ideal for burst workloads that have sudden spikes in CPU utilization, providing a temporary performance boost to help avoid slowdowns.
Intel Adaptive Boost Technology opportunistically increases the all-core turbo frequency beyond previous Turbo Boost clock speeds, even when Thermal Velocity Boost conditions aren't met. Benefits can be seen with multi-threaded programs that scale with multiple cores, which includes many games. It can also help in multitasking situations, such as when gaming, streaming, and chatting all at once through different applications.
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Accelerates AI inference to improve performance for deep learning workloads.
Intel
24
Core i9-14900F
Core i9
Normal
LGA 1700
32
N/A
BX8071514900F
1 kg
N/A
| Feature | Value |
|---|---|
| Product Collection | Intel® Core™ i9 Processors (14th gen) |
| Code Name | Products formerly Raptor Lake |
| Vertical Segment | Desktop |
| Processor Number | i9-14900F |
| Lithography | Intel 7 |
| Use Conditions | PC/Client/Tablet |
| Cores | 24 (8 performance + 16 efficient) |
| Threads | 32 |
| Max Turbo Frequency | 5.8 GHz (Intel® Thermal Velocity Boost) |
| Performance-Core Max Turbo Frequency | 5.4 GHz |
| Efficient-Core Max Turbo Frequency | 4.3 GHz |
| Performance-Core Base Frequency | 2 GHz |
| Efficient-Core Base Frequency | 1.5 GHz |
| Cache | 36 MB Intel® Smart Cache |
| Total L2 Cache | 32 MB |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 219 W |
| Memory | |
| Max Size | 192 GB |
| Types | DDR5 5600 MT/s, DDR4 3200 MT/s |
| Channels | 2 |
| Max Bandwidth | 89.6 GB/s |
| Integrated Graphics | |
| Name | Intel® UHD Graphics 770 |
| Base Frequency | 300 MHz |
| Max Dynamic Frequency | 1.65 GHz |
| Outputs | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Execution Units | 32 |
| Max Resolutions | |
| HDMI | 4096 x 2160 @ 60Hz |
| DP | 7680 x 4320 @ 60Hz |
| eDP | 5120 x 3200 @ 120Hz |
| Direct Media Interface (DMI) | Revision 4.0 |
| Max DMI Lanes | 8 |
| Scalability | 1S Only |
| PCI Express | |
| Revisions | 5.0 and 4.0 |
| Configurations | Up to 1x16+4, 2x8+4 |
| Max Lanes | 20 |
| Socket | FCLGA1700 |
| Max CPU Configuration | 1 |
| Thermal Solution | PCG 2020C |
| TJUNCTION | 100°C |
| Package Size | 45.0 mm x 37.5 mm |
