SKU: BX8071513700KF
users viewing this item right now

Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor's Efficient-cores for multitasking.
The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 24 threads are assigned to the right core at the right time.
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.
Accelerates AI inference to improve performance for deep learning workloads.
General
| CPU Model | Intel Core i7-13700KF (13th Gen) |
| CPU Socket | LGA 1700 |
| Manufacturing Process | 10 nm |
| Maximum CPU Configuration | 1S |
| Maximum Number of PCIe Lanes | 16 (Revision 5.0) 4 (Revision 4.0) |
| Unlocked | Yes |
Performance
| Number of Cores | 16 (8 x P-Cores + 8 x E-Cores) |
| Number of Threads | 24 |
| Base Clock Speed | P-Core: 3.4 GHz E-Core: 2.5 GHz |
| Maximum Boost Speed | P-Core Turbo: 5.3 GHz E-Core Turbo: 4.2 GHz |
| L3 Cache | 30 MB |
Memory Support
| Maximum Capacity | 128 GB |
| Memory Support | DDR5 Up to 5600 MHz DDR4 Up to 3200 MHz |
| ECC Memory | No |
| Channel Architecture | Dual Channel |
| Maximum Memory Bandwidth | 89.6 GB/s |
| Optane Memory Support | Yes |
Power
| Thermal Design Power (TDP) | 125 W |
| Included Thermal Solution | None |
| Maximum Temperature | 212°F / 100°C |
| Thermal Monitoring Technologies | Yes |
Technology
| AES Support | Yes |
| Extension | AVX 2.0, AVX-512, SSE 4.1/4.2 |
| Instruction Set | 64-Bit |
| Virtualization | Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT) |
| DMI | DMI4 (16 GT/s) |
| vPro Support | No |
| Performance Technologies | Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Turbo Boost 2.0, Turbo Boost Max 3.0 |
| Security Technologies | Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology |
| Integrated Graphics | None |
Packaging Info
| Package Weight | 0.2 lb |
| Box Dimensions (LxWxH) | 5.1 x 4.1 x 1.9" |
