Gigabyte Z890 AERO G LGA 1851 ATX Motherboard (Snow White)

GIGABYTE Z890 AERO G (Series 2) LGA 1851, ATX, DDR5, 5xM.2, PCIe 5.0, Thunderbolt 4, WIFI7, Dual 2.5Gbe LAN, EZ-Latch

Feature

• Supports Intel® Core™ Ultra processors (Series 2)
• VisionLINK/TB : One USB-C® Port for Video, Data Transfer and Charging
• Ultimate Scalibility : 2*PCIe x16 slots for Multi-GPU
• Extended Connectivity : THUNDERBOLT™ 4 Type-C®with DP-Alt, HDMI
• Ultra-Fast Storage : 5*M.2 slots, including 1* PCIe 5.0 x4
• Blazing Fast Networks : Daul 2.5 GbE LAN and Wi-Fi 7 with directional Ultra-high gain antenna
• Digital twin 16+1+2 phases VRM solution
• WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
• EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design
• EZ-Latch Click : M.2 heatsinks with screwless design
• Sensor Panel Link : Onboard video port for hassle-free in-chassis panel setup
• Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
• D5 Bionic Corsa for Infinite Memory Performance
• AI Perfdrive : Provides optimal and customized BIOS preset profile for users
• Premium Compatibility : 4*DDR5 with XMP Memory Module Support
• Efficient Thermal : VRM Thermal Armor Advanced & M.2 Thermal Guard L
• High-Res Audio : ALC1220 & WIMA Audiophile Grade Capacitors
• PCIe UD Slot X : PCIe 5.0 x16 slot with 10X strength for graphics card
• Ultra Durable PCIe Armor : The metal back plate of PCIe x16 slot for enhanced durability

CREATIVITY STARTS HERE

Gigabyte AERO series motherboards present an innovative design for content creators to handle demanding creative tasks like 3D rendering and long-form video editing. ．Superior Connectivity ．Expandable Graphics ．Ultra-fast Storage

16*+1+2 Twin Digital VRM Design

• 80A Smart Power Stage
• 2X Copper PCB
• Premium Choke and Capacitor

Intel® Core Ultra processors (Series 2) Support

UD Power connector

• 24 pin ATX Power Connector
• 8+8 pin CPU with UD Solid Pin

4 x DIMMs, Dual Channel DDR5

5 x M.2 Slots

• 1 x PCIe 5.0 M.2 Slot
• 4 x PCIe 4.0 M.2 Slots

VisionLink/ TB

Simplify Your Connections. Connected to GIGABYTE VisionLINK/ TB port, you can transfer data, video and power charging via a single USB Type-C® cable.

VisionLINK TB, Your Thunderbolt™ 4

GIGABYTE VisionLINK TB is based on Thunderbolt™ 4, delivers 40Gb/s high-bandwidth speeds, data, video, 60W power, and USB4™ compliance devices with the simplicity of just one cable to make your work better than ever.

DisplayPort™ Alternate Mode with USB Power Delivery.

VisionLink/ TB comes with data transfer capabilities, DisplayPort Alternate Mode for video, and 60W of power for device charging.

USB Power Delivery

With the design of USB Power Delivery(PD) Profile 4 and goes up to 60W specific. It is a specification for handling higher power and allows a range of devices to fast charge over a USB connection. DisplayPort™ Alternate Mode

• Alternate mode is the feature in USB Type-C® allowing for standard USB Type-C® connectors to carry both USB signal and non USB data like video signal.

DisplayPort™ Alternate Mode with USB Power Delivery.

VisionLink/ TB comes with data transfer capabilities, DisplayPort Alternate Mode for video, and 60W of power for device charging.

USB Power Delivery

With the design of USB Power Delivery(PD) Profile 4 and goes up to 60W specific. It is a specification for handling higher power and allows a range of devices to fast charge over a USB connection. DisplayPort™ Alternate Mode Alternate mode is the feature in USB Type-C® allowing for standard USB Type-C® connectors to carry both USB signal and non USB data like video signal.

One Port For All.

Video, Data Transfer, Charging

Thunderbolt™ 4 Compatible USB4

The Thunderbolt™ 4 Compatible USB4 port delivers ultra-fast 40Gb/s data transfer, DisplayPort 1.4a support, connectivity for up to 5 devices including multiple 4K/8K displays, and power delivery.

Dual PCIe x 16 slots for Multi-GPU

Dual PCIe 5.0 x16 slots (run x16, x8) to deliver premium graphics performance for superior rendering capabilities, more immersive gaming experience, and AI trainings.

5X M.2 Slots Fast Storage

With four onboard PCIe 5.0/ 4.0 M.2 slots, Z890 AERO G is perfect for creators, enthusiasts, AI operation to RAID multiple NVMe devices for demanding workloads

Wi-Fi 7 brings you the Ultimate VR experience

Wi-Fi 7 transforms the VR landscape with its exceptional bandwidth and minimal latency, delivering an unparalleled, seamless immersive VR experience.

Dual 2.5GbE LAN

The Dual 2.5GbE LAN is perfectly designed for content creation, media centers, workstations, and AI operation. Besides providing ultra-fast network speed, the dual LAN design can ensure constant network availability, load balancing, and smoother high-resolution video streaming.

up to 2.5X faster than Gigabit Ethernet

Unparalleled audio

True High-Fidelity Music

Dive into enveloping surround sound and enjoy DSD audio playback with the Realtek ALC1220 Codec. Audiophile Grade Capacitors WIMA & Premium Grade Audio capacitors ensure consistent power delivery, recreating a professional studio-quality sound experience.

Easy & Friendly

Hassle-free Assembly

Our cutting-edge motherboard is designed for the ultimate DIY experience

WIFI EZ-Plug

The WIFI EZ-Plug design integrates Wi-Fi antenna plugs into one adapter, EZ to install.

Memory

Infinite Memory Performance

AERO motherboards boost DDR5 memory performance and offer top-notch compatibility using various advanced methods.

Effortlessly Boost Your DDR5 Memory Speed

DDR5 XMP Booster feature offers ready-to-use settings derived from analysis of memory IC and PMIC vendor. This allows users to maximize DDR5 memory performance without the hassle of manual tweaking for overclocked DDR5 memory kits.

* DDR5 MEMORY UPGRADE involves DDR5 memory overclocking, overclocking capability depends on users' hardware configuration.

Boost instantly

Instant memory performance uplift

Hands-off memory tuning

Eliminate manual entry of complex memory settings such as clock, voltage, and timings.

Hassle-free overclocking

Seamlessly overclock for both standard and XMP 3.0 DDR5 memory frequencies.

Incorporated database

Built-in library of pre-optimized configurations for diverse memory chip suppliers

Boost DDR5 Memory Performance with Optimized Tuning:

Leverage XMP 3.0 User Profile to fine-tune memory settings for peak system performance.

Customizable SPD Profiles or retrieve from database:

Create and transfer two custom SPD profiles between systems.

Quick Performance Simulator:

Rapidly assess potential memory performance by entering clock speeds and timing parameters.

Profile Management:

Store and retrieve memory configurations for online sharing.

Unlock non-overclockable DDR5 Potential:

Enhance clock speeds of non-overclockable DDR5 modules.

Instant Reset:

Revert memory settings with a single click.

Auto CPU & DDR5 Memory Boost

With just a single click, unleash the full potential of CPU & DDR5 memory, instantly boosting your gaming and work efficiency.

One-Click Acceleration:

Enhance CPU & DDR5 speeds with a single click.

• Real time Analyze
• OC accuracy UP
• EZ to Pro

AI SNATCH Engine

The AI model, trained by AI TOP on diverse overclocking datasets, improves precision and stability while optimizing performance. This model serves as the core of AORUS AI Snatch software.

• OC to 20% higher speed
• OC Efficiency UP
• No more try and error
• Optimal performance-stability balance.

AI-Driven PCB Technology -Redefining PCB Design with Artificial Intelligence

AI-Driven PCB Technology employs AI algorithms to optimize vias, routing and stackups. It ensures peak performance and signal integrity across single and cross-layer throughout the design process.

• AI-ViaFusion TechnologyOptimized vias & pads for signal integrity
• AI-Trace TechnologySmart routing for peak performance
• AI-Layer TechnologyTailored stackups for enhanced functionality

AI-ViaFusion™ Technology - AI-Powered Excellence in Signal Integrity

Reduction in Signal Reflection Up to 28.2% AI-ViaFusion, an AI-assisted via optimization technology, determines optimal via and pad sizes across PCB areas. This technology enhances cross-layer signal integrity and transmission efficiency, outperforming traditional design methods.

Best-in-class Signal Quality

• Superior signal transmission efficiency
• Dramatically reduced signal reflection
• Elevated signal quality and reliability
• Enhanced cross-layer PCB signal performance

AI-ViaFusion Technology - AI-Engineered Via Design Formula

AI-ViaFusion is a proprietary AI-generated hybrid via structure design. This PCB technology, validated through AI simulations and testing, aims to enhance high-speed signal transmission.

• Optimized Via DesignVaried via sizes for optimized signal and power paths
• Driven Pad OptimizationCustom pad sizes for performance and production balance
• Precision Impedance MatchingVia & pad sizes selected for optimal signal impedance

Unlock AI-Powered Performance with AI-ViaFusion Technology

• Minimized Insertion LossOptimized vias reduce signal loss
• Enhanced Return LossPrecision impedance matching reduces reflections
• Optimized Eye DiagramWider eye opening improves signal integrity

*Eye Diagram: Signal quality assessment tool in digital communications. Overlays bit cycle waveforms, forming eye-like pattern. Larger, clearer opening indicates better signal quality and transmission reliability.

HyperTune BIOS - Advanced MRC Optimization

Memory Reference Code (MRC) is a critical component in BIOS that initializes and configures system memory. HyperTune BIOS leverages AI to optimize MRC, pushing memory performance to new heights while maintaining system stability. Benefits of HyperTune BIOS MRC Optimization

• Boosted memory clock speeds
• Faster system response
• Improved stability under load
• Auto-adapts to memory modules

Sturdy VRM Design

Steady Power

Better Play AERO Series, steady power keeps your creation smooth.

Digital Twin VRM Design

Delivers consistent, high-powered performance to elevate your overclocking to the next level.

VCORE Phases SPS 80A

Unlock the full power of your multi-core CPU for unmatched performance.

*8+8 phases parallel power design

VCCGT Phase DrMOS 40A

Optimized for integrated GPU performance and memory management within the CPU.

VCCSA Phases SPS 80A

Deliver reliable power to your CPU-connected PCIe lanes for uninterrupted performance.

Cooling

Comprehensive Thermal

AERO motherboards come with advanced full-metal thermal design and durable heatsinks to keep your system cool and efficient

Ultra Durable™

Born from Ultra Durable™

Technology embodies our commitment to excellence, providing gamers with a platform that's not only powerful but also built for longevity and reliability. AERO series motherboards are engineered to endure and excel.

PCIe UD Slot X

The latest PCIe UD Slot X offers unparalleled robustness, delivering superior protection for your graphics card.

10X load-bearing capacity

integrated, single-piece design anchored to a exclusive backplate

Inner Lining Rubber Strip

Safeguards your graphics card's PCB against potential damage

Zinc Alloy

Provides effective EMI shielding for high-frequency signals

UD Power Connector

Our innovative UD Power Connector design enhances power conductivity and thermal dissipation.

Solid Pins

Delivers superior conductivity and signal transmission and reduces metal wear from repeated connections.

Ultra Durable PCIe Armor

Features a metal reinforcement plate for the PCIe x16 slot, enhancing stability and durability to support large graphics cards.

Tailored Computing

Collaborative Excellence in Computing

GIGABYTE motherboards showcases our devotion to BIOS improvement. Through synergy with our user community, we democratize next-level computing power.
