GIGABYTE Ultra Durable™ motherboards built with optimal components inside out provide the prime performance and timeless platform.
The ultimate connectivity with blazing data-transfer speeds through the next generation network and storage.
Innovative and intuitive hardware, software, and BIOS interface design to create your personal style.
Gigabyte
B860
DDR5
mATX
LGA 1851
Black
B860M-K
1 kg
N/A
| Category | Specification |
|---|---|
| CPU | LGA1851 socket – Intel® Core™ Ultra Processors (Series 2) |
| Chipset | Intel® B860 Express Chipset |
| Memory | 2 × DDR5 DIMM, up to 128 GB Supports 8800(OC) down to 5600 MT/s Dual channel, ECC (non-ECC mode), XMP |
| Onboard Graphics | 1 × HDMI 2.1 (4096×2160@60 Hz) – CPU dependent |
| Audio | Realtek® ALC897 – High Definition Audio – 2/4/5.1/7.1-channel + S/PDIF Out |
| LAN | Realtek® GbE LAN (1 Gbps/100 Mbps/10 Mbps) |
| Expansion Slots | 1 × PCIe 4.0 x16 (CPU) 1 × PCIe 3.0 x1 (Chipset) |
| Storage | 2 × M.2 PCIe 4.0 x4/x2 (Chipset) 4 × SATA 6Gb/s RAID 0/1/5/10 |
| USB (Rear) | 4 × USB 3.2 Gen 1 2 × USB 2.0/1.1 |
| USB (Internal) | 1 × USB 3.2 Gen 1 header (2 ports) 2 × USB 2.0 headers (4 ports) |
| Internal I/O | 24-pin ATX + 8-pin 12V CPU & System fan headers 2 × Addressable RGB Gen2 headers TPM header, COM header, Clear CMOS jumper |
| Back Panel | PS/2, HDMI, 4× USB 3.2 Gen 1, 2× USB 2.0, RJ-45, 3× audio jacks |
| BIOS | 256 Mbit AMI UEFI BIOS – PnP 1.0a, ACPI 5.0, SM BIOS 2.7 |
| Unique Features | GIGABYTE Control Center (GCC) – Q-Flash – Smart Backup |
| Bundled Software | Norton® Internet Security (OEM) – LAN bandwidth management |
| OS Support | Windows 11 64-bit – Windows 10 64-bit |
| Form Factor | Micro ATX – 24.4 cm × 21.5 cm |
