Nzxt C550 550 Watt 80 Plus Bronze SMPS

Features:

The C550 brings 550 watts of reliable power to your battle station

Overview :

Power your creative, productive, and entertainment experiences by including the NZXT C550 550W 80 PLUS Bronze Semi-Modular ATX Power Supply in your computer build. Designed primarily for relatively low power systems, this standard semi-modular ATX power supply delivers up to 550W across one +12V rail with a power 80 PLUS Bronze energy efficiency rating of up to 83% at full load. The built-in 120mm, 1200 rpm fluid-dynamic fan helps to maintain optimal temperatures under intense workloads.

80 PLUS Bronze

This 550W PSU features 80 PLUS Bronze certification and is rated to deliver up to 83% energy efficiency rating at 100% load.

Device Support

Cables are included to power up to four PCIe devices, six SATA drives, and three 4-pin peripherals such as fans.



KEY SPECS
Dimensions W 150mm x L 140mm x H 86mm
Material(s) Steel, PCB and plastic
Compliance Standard ATX12V v2.4 / EPS12V v2.92
AC Input Rating 100V-240V 8A-4A 50Hz-60Hz
GENERAL
Regulations & Certifications (EMC & Safety) CB / CE / FCC / TUV / cTUV-SUDus / China CCC / Taiwan BSMI R33245/ Australia RCM / EAC / UKCA / WEEE /
Hazardous Materials RoHS & China RoHS
DC OUTPUT RATING
Voltage +3.3V / +5V / +5VSB /+12V / -12V
Max Load 20A / 20A / 2.5A / 45.5A / 0.3A
Voltage Regulation ±5% / ±5% / ±5% / ±5% / ±10%
Ripple & Noise < 50 mV p-p / < 50 mV p-p / < 50 mV p-p / < 120 mV p-p / < 120 mV p-p
Output Power (watt) 110 / 110 / 12.5 / 546 / 3.6
Total 550
FAN SPECS
Dimensions 120 x 120 x 25 (mm)
Speed 2400 ±10% RPM
Airflow 72.90 CFM
Noise <44 dBA
Bearing FDB (Fluid Dynamic Bearing)
ENERGY EFFICIENCY
Rating 80 Plus Bronze
10% loading 82%
20% loading 83%
50% loading 87%
100% loading 83%
OPERATION
PF Correction [email protected]
MTBF 100,000 hours
Operation Temperature 0 to 40°C
OUTPUT CONNECTOR(S)
24-pin ATX Power 1
4+4-pin CPU power 2
6+2-pin PCIe power 4
SATA Power 6
Peripherals 3
Warranty 5 Years
Note *** Features, Price, Specifications are subject to change without notice.
Weight 2 kg
Dimensions 15 × 15 × 9 cm
