MSI Mag Pano 110R PZ Mid Tower ATX Cabinet (White)
SKU: Mag-Pano-110-PZ-White
users viewing this item right now
₹17999
₹7495
Save Extra
Availability
In Stock
- Support Back-Connect ATX Motherboard
- Airflow Optimized
- Dual Layer Blades Fan
- Versatile Cooling Support
MSI Mag Pano 110R PZ Mid Tower ATX Cabinet (White)
Feature
- Supported ATX and Micro-ATX Back-connect motherboard
- Supports 360 mm radiator on the top, side and bottom
- 270-degree panoramic tempered glass
- Pre-installed with 3 x 120 mm ARGB Reverse-blade fan at the side and 1 x 120 mm ARGB fan at the rear
- Synergize with a compatible MSI motherboard through bridging with a USB 20Gbps Type-C (20Gbps) port for high speed data transmission
/11-320-071/1.jpg)
SMART IN SPACING
The MAG PANO 110R PZ WHITE is a compact mid-tower case engineered for optimal airflow and compatibility. It supports up to 10 fans, with four pre-installed, and features enhanced venting for superior heat dissipation. Designed for flexibility, it accommodates GPUs up to 400mm in length and an ATX or Micro-ATX back-connect motherboard. A 270-degree panoramic design highlights your build, while removable glass panels and an ARGB fan hub simplify installation and cable management./11-320-071/2.jpeg)
1-to-5 ARGB Fan Control Hub
This PC case includes a pre-installed 1-to-5 ARGB Fan Control Hub, simplifying cable management and ARGB lighting control./11-320-071/3.jpeg)
Extensive Compatibility
The MAG PANO 110R PZ WHITE is a compact mid-tower case that offers ample space:Motherboard support:
- Regular: ATX / Micro-ATX / Mini-ITX
- Back-connect: ATX / Micro-ATX
Component clearances:
- CPU Cooler height: 160 mm
- GPU length: 400 mm
- PSU length: Up to 200 mm
/11-320-071/4.jpeg)
Extensive Cooling Support
The MAG PANO 110R PZ WHITE fan cooling options include:- Top: 3 x 120 mm / 2 x 140 mm
- Front: NA
- Rear: 1 x 120 mm
- Side: 3 x 120 mm / 2 x 140 mm
- Bottom: 3 x 120 mm (Above the power shroud)
- Side: 3 x 120 mm ARGB Fan (Reverse-blade)
- Rear: 1 x 120 mm ARGB Fan
/11-320-071/5.jpeg)
Airflow Optimization
Increased number of vents on the sides and front of the case to enhance overall heat dissipation. Supports up to 10 fan installations and comes pre-installed with three reverse-blade fans on the side and one regular fan at the rear./11-320-071/6.jpeg)
270-Degree Panoramic View
The case boasts a 270-degree panoramic design with tempered glass, providing an expansive view to showcase detailed components./11-320-071/7.jpeg)
Drive Mount Support
The SSD bracket features a tool-less design, and the HDD cage is adjustable, allowing users to build systems with greater flexibility. Storage options:- 2 x 2.5" SSD
- 2 x 3.5” HDD
- 2 x 2.5“ SSD / 3.5 " HDD Combo Tray
/11-320-071/8.jpeg)
Dust Protection
The case includes two removable filters on the top and bottom, helping protect internal components from dust buildup./11-320-071/9.jpeg)
Panel I/O
The side I/O panel features a USB 20Gbps Type-C port for high-speed data bridging to compatible motherboards.- 1 x USB 20Gbps (Type-C)
- 2 x USB 5Gbps (Type-A)
- Mic in / Audio out
- LED Switch Button
- Power Button
Key Features
| Product Name | MAG PANO 110R PZ / WHITE |
| Case Form Factor | Mid-Tower |
| Motherboard Form Factor Support | Regular: ATX / Micro-ATX / Mini-ITXBack-connect: ATX / Micro-ATX |
| I/O Ports | 1 x USB 20Gbs (Type-C) 2 x USB 5Gbs (Type-A) 1 x Audio-Out / Mic-in 1 x LED Button 1 x Power Button |
| Drive Mount Support | 2 x 2.5“ 2 x 3.5“ 2 x 2.5″/3.5″ combo |
| Expansion Slot | 7 |
| Maximum GPU Length | 400 mm / 15.75 inches |
| Maximum CPU Cooler Height | 160 mm / 6.30 inches |
| Power Supply Support | ATX |
| Maximum PSU Length | 200 mm / 7.87 inches |
| Fan Size Support | Top: 3 x 120 mm / 2 x 140 mm Front: NA Rear: 1 x 120 mm Side: 3 x 120 mm / 2 x 140 mm Bottom: 3 x 120 mm (Above the power shroud) |
| Pre-Installed Fan Type | Side: 3 x ARGB Fan (Reverse Blades Fan) Rear: 1 x ARGB Fan |
| Pre-Installed Fan SIze | Side: 3 x 120 mm Rear: 1 x 120 mm |
| Radiator Size Support | Top: 120 / 140 / 240 / 280 / 360 mm Front: NA Rear: 120 mm Side: NA Bottom: NA |
| Dimensions (DxWxH) | 420 x 225 x 485 mm / 16.54 x 8.86 x 19.09 inches |
| Warranty | 2 Years |
| Note** | **Prices, Specifications & Features are subject to change without notice |
Color
White
Brands
MSI
Warranty
2 Year
Ean-Upc-Code
824142396322
Product-Type
Normal
Radiator-Size
360mm
Case-Form-Factor
Mid Tower
Lighting-Profile
ARGB
Motherboard-Size
ATX
