MSI MAG B660M Mortar DDR5 Intel Motherboard Supports Intel 12th , 13th & 14th Gen Processors
Brand:
MSI
- MAG B660M Mortar Supports 12th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
- MAG B660M Mortar Supports DDR5 Memory, up to 6200+(OC) MHz
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
- Latest Network Solution: Onboard 2.5G LAN plus Gigabit LAN with LAN Manager deliver the best online experience without lag
... people are viewing this right now
Original price was: ₹26,250.00.₹18,999.00Current price is: ₹18,999.00.
Out of stock
Email when stock available
MSI MAG B660M Mortar DDR5 Intel Motherboard
Features:
- MSI MAG B660M Mortar Supports 12th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
- Supports DDR5 Memory, up to 6200+(OC) MHz
- Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
- Latest Network Solution: B660M Mortar Onboard 2.5G LAN plus Gigabit LAN with LAN Manager deliver the best online experience without lag
- Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs
- Lightning USB 20G: Built-in USB 3.2 Gen 2×2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1
- Audio Boost: B660M Mortar Reward your ears with studio grade sound quality
- Multi-GPU: B660M Mortar With Steel armor PCIe slots. Supports AMD Crossfire™
MSI: For Gamers & Creators
MSI is one of the most trusted names in gaming and esports with countless hours and significant resources invested into premier esports leagues and tier-1 gaming teams. By supporting and working with the best of the best, MSI is able to integrate competitive gaming knowledge and aspirations with technological innovation to create new products that shatter today’s performance limits.
MAG B660M MORTAR
Conquer the Battlefield
The MAG B660M MORTAR is a gaming oriented Micro-ATX motherboard constructed around the latest Intel B660 chipset that balances value with cutting-edge hardware.
- Supports Intel Core 12th Gen Processors (LGA 1700)
- 12 Duet Rail Power System (60A/DrMOS)
- 4 DIMMS DDR5 with Memory Boost: Dual Channel (128GB Max. / 6200MHz OC)
- Lightning Gen4 & Turbo Gen3 M.2 slots with Shield Frozr
- 1 x PCI-e 4.0 x16, 1x PCI-e 3.0 x16 slots (AMD CrossFire)
- 7.1 HD Audio with Audio Boost
- 2.5G LAN & Bluetooth 5.2
B660 Chipset, 12 Duet Rail Power System, Smart Cooling, DDR5 Memory Boost
|
|
|
|
|
|---|---|---|---|
Supports Intel Core 12th Gen ProcessorsThe MAG B660M MORTAR DDR5 motherboard supports 12th Gen Intel Core processors.
Intel B660 chipset motherboards support memory overclocking but not CPU overclocking. |
12+1+1 Duet Rail Power SystemWith its dual 8 pin power connectors and exclusive Core Boost Technology (60A, DrMOS), the MAG B660M MORTAR DDR5 is able to sustain heavy CPU power loads to support system-demanding game settings: 1. Digital PWM IC 2. 1-Phase AUX Power 3. 1-Phase GT Power 4. 12 Duet Rail CPU Power System |
Integrated Cooling FeaturesVRM Cooling: Features an extended heatsink and 7W/mK thermal pads. PCB Cooling: Premium 6-layer printed circuit design with 2 oz. thickened copper improves heat dissipation & reliability. SSD Cooling: M.2 Shield Frozr prevents thermal throttling. System Cooling: Connect and synchronize cooling with strategically placed pin-headers – including a dedicated pump-fan header. |
4 x DDR5 Dual Channel (6200 MHz OC)Memory Boost: A fully-isolated DDR circuit delivers pure data signals for optimal gaming and overclocking performance. XMP profiles in MSI BIOS are MSI OC LAB tested and can be easily enabled with auto power settings for optimized memory speed and stability. |
PCI-e 4.0 x16 Slot, Cutting-Edge Storage Performance
|
|
|
|
|
|---|---|---|---|
Fortified PCI-e 4.0 x16MSI PCI Express Steel Armor slots are secured to the motherboard with extra solder points to support the weight of heavy graphics cards. When every advantage in games counts, Steel Armor also shields the point of contact from electromagnetic interference:
|
Gen4 M.2 ConnectorsThe MAG B660M MORTAR motherboard features MSI’s latest M.2 slots (Intel Optane supported):
*M.2 specifications may vary depending on the CPU installed. |
M.2 Shield FrozrEven the world’s fastest SSDs will automatically slow if thermal throttling firmware detects excessively high temperatures. M.2 Shield Frozr is MSI’s most advanced thermal solution, offering the best possible protection to ensure maximum SSD transfer speed performance. |
Bluetooth 5.22.5G LAN: A 2.5Gbps LAN controller delivers a premium network gaming experience. USB 3.2 Gen 2×2 Type-C: Enables ultra-fast 20Gbps data transfer rates between devices. HD Audio: 7.1-Channel High Definition Audio with Audio Boost 5 & S/PDIF output.
|
| Processor |
|
| Chipset |
Intel® B660 Chipset
|
| Memory |
|
| Expansion Slot |
|
| Multi-GPU | Supports 2-Way AMD® CrossFire™ Technology |
| Onboard Graphics |
|
| Storage |
|
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| USB |
Intel® B660 Chipset
USB Hub-GL3590
USB Hub-GL850G
|
| Audio |
Realtek® ALC1200 Codec
|
| LAN | 1x Realtek® 8125BG 2.5Gbps LAN controller |
| Internal connectors |
|
| LED Feature |
|
| Back panel ports |
|
| Dimensions |
|
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
