SKU: KF552C40BB-32
users viewing this item right now
Kingston FURY Beast is a 4G x 64-bit (32GB) DDR5-5200 CL40 SDRAM (Synchronous DRAM) 2Rx8, memory module, based on sixteen 2G x 8-bit FBGA components per module. The module supports Intel® Extreme Memory Profiles (Intel XMP) 3.0. Each module has been tested to run at DDR5-5200 at a low latency timing of 40-40-40 at 1.25V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The JEDEC standard electrical and mechanical specifications are as follows.





| Model: | KF552C40BB-32 |
| Capacity: | 32GB |
| Memory: | DDR5 |
| Latency: | CL 40 |
| Row Cycle Time (tRCmin) | 48ns(min.) |
| Speed: | 5200Mhz |
| Voltage: | 1.25V |
| Refresh to Active/Refresh Command Time (tRFCmin) | 295ns(min.) |
| Row Active Time (tRASmin) | 32ns(min.) |
| UL Rating: | 94 V – 0 |
| Storage Temperature: | -55 o C to +100o C |
| Dimension: | 133.35 mm x 34.9 mm x 6.62 mm |
| Warranty: | Lifetime warranty |
| Note | *** Features, Price, Specifications are subject to change without notice. |
