Kingston 32GB DDR5-5600 ECC Registered RAM Module
SKU: KSM56R46BS4PMI
users viewing this item right now
₹198000
₹104999
Save Extra
Availability
In Stock
- ECC Registered DIMM
- DDR5- 5600
- TIMING- 46-45-45
- CAS LATENCY- CL46
- VOLTAGE- 1.10V
- MEMORY KIT- 32GB (1 X 32GB)
Kingston 32GB DDR5-5600 ECC Registered RAM Module, Single-Rank, CL46, Server Memory, 288-pin DIMM, 1.1V, RoHS Compliant - KSM56R46BS4PMI-32MDI (Lifetime Warranty)
Feature
Enterprise-Grade DDR5 Memory for Maximum Server Performance
Kingston's 32GB DDR5 memory module exemplifies next-generation server performance with its advanced ECC protection and 5600MT/s speed rating. The green PCB design houses premium components including twenty 4G x 4-bit FBGA chips arranged for optimal signal integrity and thermal management. This registered DIMM leverages DDR5's innovative architecture with on-die ECC and dual 40-bit subchannels to deliver superior data reliability. Operating at just 1.1V, it provides the perfect balance of power efficiency and performance for modern enterprise servers and workstations.
Applications
- High-performance enterprise servers
- Mission-critical database systems
- Virtual machine host environments
- Advanced scientific computing platforms
FEATURES
- Power Supply: VDD = 1.1V Typical
- VDDQ = 1.1V Typical
- VPP = 1.8V Typical
- VDDSPD = 1.8V to 2.0V
- On-Die ECC
- x80 ECC (x40, 2 independent I/O sub channels)
- 32 internal banks
- Hard/Soft Post Package Repair
- Sideband access with I3C/I2C
- PCB: Height 1.23” (31.25mm)
- RoHS Compliant and Halogen-Free
Key Features
| Feature | Specification |
|---|---|
| General Information | |
| Manufacturer | KINGSTON |
| Manufacturer Part Number | KSM56R46BS4PMI-32HAI |
| Product Name | 32gb Ddr5 Ecc Registered Rdimm (hynix A + Renesas/idt) |
| Technical Information | |
| Capacity | 32gb |
| Memory Technology | Ddr5 Sdram |
| Module Configuration | 1 X 32gb |
| Speed | 5600mt/s (pc5-44800) |
| Error Checking | Ecc (error-correcting Code) |
| Signal Processing | Registered |
| Cas Latency | Cl46 |
| Rank | Single Rank X4 (1rx4) |
| Voltage | 1.1v |
| Features | |
| Based On | Twenty 4g X 4-bit Fbga Components |
| Jedec Standard Latency Timing | 46-45-45 At 1.1v |
| Power Supply | Vdd = 1.1v, Vddq = 1.1v, Vpp = 1.8v, Vddspd = 1.8v To 2.0v |
| Internal Banks | 32 Internal Banks With On-die Ecc |
| Ecc | X80 Ecc (x40, 2 Independent I/o Sub Channels) |
| Repair | Hard/soft Post Package Repair |
| Sideband Access | With I3c/i2c |
| Compliance | Rohs Compliant And Halogen-free |
| Electrical & Mechanical Specifications | |
| Row Cycle Time (trcmin) | 48ns |
| Refresh To Active/refresh Command Time (trfcmin) | 295ns |
| Row Active Time (trasmin) | 32ns |
| Row Precharge Time (trpmin) | 16ns |
| Ul Rating | 94 V - 0 |
| Operating Temperature | 0°c To +95°c |
| Storage Temperature | -55°c To +100°c |
| Physical Characteristics | |
| Form Factor | 288-pin Rdimm |
| Shipping Dimensions | 5.3 In (width) X 1.2 In (length) |
| Shipping Weight | 0.20 Lb |
| Note | Features, price, and specifications are subject to change without notice. Images are for representation only. |
Brands
Kingston
Ram-Size
32GB
Ram-Type
DDR5
Ean-Upc-Code
740617337204
Product-Type
Normal
Ram-Frequency
5600 MHz
