Gigabyte
Z890
582605808645
Gigabyte Aorus
E-ATX
LGA 1851
Black
Z890-A-MASTER-AI-TOP
2 kg
N/A
| Category | Specifications |
|---|---|
| CPU | LGA1851 socket |
| Supported Processors | Intel® Core™ Ultra Processors |
| Cache | L3 cache varies with CPU |
| Chipset | Intel® Z890 Express Chipset |
| Memory Type | DDR5 |
| Memory Speed Support | DDR5 9500(O.C) / 9466(O.C) / 9333(O.C) / 9200(O.C) / 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C) / 7400(O.C) / 7200(O.C) / 7000(O.C) / 6800(O.C) / 6600(O.C) / 6400 / 6200 / 6000 / 5800 / 5600 MT/s |
| Memory Slots | 4 x DDR5 DIMM |
| Max Memory Capacity | Up to 256GB (64GB per DIMM) |
| Memory Architecture | Dual Channel |
| ECC Support | ECC Un-buffered DIMM 1Rx8 / 2Rx8 (operates in non-ECC mode) |
| Non-ECC Support | Non-ECC Un-buffered DIMM 1Rx8 / 2Rx8 / 1Rx16 |
| Memory Profiles | XMP |
| CUDIMM Support | Yes |
| Onboard Graphics | Integrated Intel® HD Graphics support |
| Thunderbolt Video Output | 2 x Intel® Thunderbolt™ 4 (USB4® Type-C), supports DisplayPort / Thunderbolt video, up to 5120x2880@60Hz or 3840x2160@240Hz |
| Front HDMI Output | 1 x Front HDMI, max 1920x1080 @ 30Hz, HDMI 1.4 |
| Graphics Standards | DisplayPort 2.1, HDCP 2.3 |
| Multi-Display Support | Up to Triple Display simultaneously |
| Rear Audio Chip | ESS ES9280 chip |
| Rear Audio Features | DTS:X® Ultra, High Definition Audio, 2-channel |
| Front Audio Chip | ESS ES9118 DAC chip |
| LAN | 2 x Marvell® AQtion AQC113C 10GbE LAN chips |
| LAN Speeds | 10 Gbps / 5 Gbps / 2.5 Gbps / 1 Gbps / 100 Mbps |
| Wireless Module | Intel® Wi-Fi 7 BE200NGW |
| Wi-Fi Standards | 802.11a / b / g / n / ac / ax / be |
| Wi-Fi Bands | 2.4GHz / 5GHz / 6GHz |
| Bluetooth | Bluetooth 5.4 |
| Wi-Fi Feature | 11be 320MHz wireless standard |
| Main PCIe Slot | 1 x PCI Express x16 (PCIEX16), PCIe 5.0 x16 |
| PCIEX16 Sharing | Operates at x8 when PCIEX8 slot is populated |
| Secondary PCIe Slot | 1 x PCI Express x16 (PCIEX8), PCIe 5.0 x8 |
| Third PCIe Slot | 1 x PCI Express x16 (PCIEX4), PCIe 4.0 x4 |
| M.2 Slot 1 | 1 x M2A_CPU, 25110/22110/2580/2280, PCIe 5.0 x4/x2 |
| M.2 Slot 2 | 1 x M2B_CPU, 22110/2280, PCIe 4.0 x4/x2 |
| M.2 Slot 3 | 1 x M2Q_SB, 22110/2280, PCIe 4.0 x4/x2 |
| M.2 Slot 4 | 1 x M2M_SB, 22110/2280, SATA / PCIe 4.0 x4/x2 |
| SATA Ports | 4 x SATA 6Gb/s |
| RAID NVMe | RAID 0 / 1 / 5 / 10 |
| RAID SATA | RAID 0 / 1 / 5 / 10 |
| Rear Thunderbolt Ports | 2 x Intel® Thunderbolt™ 4 (USB Type-C®), up to 40Gbps |
| Rear USB 3.2 Gen 2 Type-A | 10 x Type-A (red) |
| Internal USB Type-C Header | 1 x USB Type-C®, USB 3.2 Gen 2x2 |
| Internal USB 3.2 Gen 1 Headers | 2 x headers (supports 4 ports) |
| Internal USB 2.0 Headers | 2 x headers (supports 4 ports) |
| Power Connectors | 1 x 24-pin ATX / 2 x 8-pin ATX 12V |
| Cooling Headers | 1 x CPU fan / 1 x CPU fan-water pump / 4 x system fan / 4 x system fan-water pump |
| RGB Headers | 4 x Addressable RGB Gen2 / 1 x RGB LED strip |
| Internal Storage Connectors | 4 x M.2 Socket 3 / 4 x SATA |
| Front Panel Headers | 1 x front panel / 1 x front panel audio |
| Extra Headers | 1 x noise detection / 1 x TPM / 2 x temperature sensor |
| Internal Buttons / Jumpers | Power button / Reset button / Reset jumper / Clear CMOS jumper |
| Special Feature | Voltage Measurement Points |
| Back Panel Utility | 1 x Q-Flash Plus button / 1 x Clear CMOS button |
| Back Panel USB | 2 x Thunderbolt™ 4 Type-C / 10 x USB 3.2 Gen 2 Type-A |
| Back Panel Network | 2 x RJ-45 |
| Back Panel Wireless | 2 x antenna connectors (2T2R) |
| Back Panel Audio | 2 x audio jacks |
| I/O Controller | iTE® I/O Controller Chip |
| Hardware Monitoring | Voltage detection / Temperature detection / Fan speed detection / Water cooling flow rate detection / Fan fail warning / Fan speed control / Noise detection |
| BIOS | 1 x 256 Mbit flash / AMI UEFI BIOS |
| BIOS Standards | PnP 1.0a / DMI 2.7 / WfM 2.0 / SM BIOS 2.7 / ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC) / Q-Flash / Q-Flash Plus / Smart Backup |
| Bundled Software | Norton® Internet Security (OEM version) / LAN bandwidth management software |
| Operating System | Windows 11 64-bit |
| Form Factor | E-ATX |
| Dimensions | 30.5 cm x 28.5 cm |
