No reviews yet. Be the first to review!
N/A
Gigabyte
DDR5
ATX
AM5
Black
X870 AORUS STEALTH
1 kg
N/A
| Specification | Details |
|---|---|
| CPU Support | AMD Socket AM5: Ryzen™ 9000/8000/7000 Series (check GIGABYTE site for latest) |
| Chipset | AMD X870 |
| Memory | 4 x DDR5 DIMM up to 256 GB (64 GB single); DDR5 8200(O.C) to 4400 MT/s; Dual channel; Non-ECC un-buffered; AMD EXPO™/XMP support (check support list) |
| Onboard Graphics | AMD Radeon™ Graphics: 1 x HDMI (4096x2160@60 Hz, HDMI 2.1); ASMedia USB4®: 2 x USB4® Type-C (3840x2160@240 Hz, DP 1.4, HDR) |
| Audio | Realtek® ALC1220; HD 2/4/5.1/7.1-channel; S/PDIF Out; DSD support |
| LAN | Realtek® 5GbE (5/2.5/1 Gbps/100 Mbps) |
| Wireless | Qualcomm® Wi-Fi 7 QCNCM865 (802.11a/b/g/n/ac/ax/be, 2.4/5/6 GHz, 320 MHz); Bluetooth 5.4 (Windows 11 required for Wi-Fi 7) |
| Expansion Slots | CPU: 1 x PCIe x16 (PCIe 5.0 x16 / 4.0 x8/x4); Chipset: 1 x PCIe x16 (x4) (shares with M2D_SB) |
| Storage | M.2 (CPU): M2A_CPU (PCIe 5.0/4.0 x4/x2, 25110/22110/2580/2280); M2B_CPU (PCIe 5.0/4.0 x4/x2, 22110/2280, unavailable on Phoenix 2); Chipset: M2C_SB/M2D_SB (PCIe 4.0 x4/x2, 22110/2280); 2 x SATA 6Gb/s; RAID 0/1/5/10 (NVMe/SATA) |
| USB (Rear) | USB4®: 2 x Type-C; CPU: 1 x Type-C (Gen 2), 4 x Gen 1, 4 x 2.0; Chipset: 2 x Gen 2 Type-A (red) |
| USB (Internal) | 1 x Type-C (Gen 2x2); 1 x Gen 1 header; 2 x 2.0 headers |
| Internal Connectors | Power: 24-pin ATX, 8/4-pin 12V; Fans/Pump: 1 x CPU fan, 1 x CPU OPT, 4 x SYS fan, 2 x SYS/WP; RGB: 3 x ARGB Gen2, 1 x RGB; Other: Front panel/audio, TPM, Q-Flash Plus, power/reset buttons, temp sensors, Clear CMOS |
| Back Panel | HDMI, 2 x antennas, 2 x USB4® Type-C, 1 x USB-C Gen 2, 2 x USB 3.2 Gen 2, 4 x Gen 1, 4 x 2.0, RJ-45, S/PDIF Out, 2 x audio jacks |
| I/O Controller | iTE® chip; H/W monitoring (voltage/temp/fan/flow, fail warning, control) |
| BIOS | AMI UEFI, 512 Mbit; PnP/DMI/WfM/SM BIOS/ACPI support |
| Unique Features | GIGABYTE Control Center, Q-Flash/Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM) |
| OS Support | Windows 11 64-bit |
| Form Factor | ATX (30.5 x 24.4 cm) |
