A series of grooves and cutouts are located behind the board and along the case edges for smart and tidy cable management, which can shorten your building time.
The 4mm tempered glass side panel is thoughtfully designed to be removed by tilting out the top first to prevent accidental drops. The non-drilled design further improves the glass panel's strength and safety.
The 2 USB 3.0 ports use the 11-core USB cables to ensure stable signal integrity. The front I/O also offers versatile connectivity, including a USB 3.1 Gen-2 Type-C port and an audio port.
The built-in ARGB and PWM connector hub is equipped with 5x 5V 3-pin and 5x PWM connectors, enabling users to expand their RGB light stripes, create a superb cooling system as well as a fantastic and gorgeous rig.
| Model | GB-AC500G |
| Case Form Factor | Mid Tower |
| M/B Type | Mini ITX / Micro ATX / ATX / E-ATX |
| Color | Black |
| Materials | Steel, Plastic, Glass |
| Dimensions | H=548 W=250 D=482 mm (Within ± 1% error) |
| Expansion slots | 8 + 3 (Requires PCIE Riser Cable) |
| 5.25" Drive Bays | None |
| 3.5“/2.5” Drive Bays | 2 |
| 2.5" Drive Bays | 2 |
| I/O Panel | USB 3.1 Gen2 Type-C x1 / USB 3.0 x2 / Audio In & Out (supports AC97 /HD Audio) |
| Pre-installed Fan | Front : 120mm x3 (ARGB & PWM) Rear : 120mm x1 (ARGB & PWM) |
| Fan Support | Front : 120mm x3 / 140mm x3 Top : 120mm x3 / 140mm x2 Rear : 120mm x1 / 140mm x1 |
| Radiator Support | Front : Max 420mm Top : Max 360mm Rear : 140mm |
| Power Supply Type | Standard ATX (Not included) |
| Maximum Compatibility | CPU Height : 190mm GPU Length : 420mm PSU Length : 220mm |
| Vertical GPU Mount | Yes (Default: 73mm total clearance / VGA holder bracket: 160mm total clearance) |
| Dust Filters | Top, Front, Bottom |
| RGB Lighting | Yes (Support RGB Fusion 2.0) |
| Weight | N.W. 13.4 Kg |
| Package Dimensions | H=594 W=336 D=584 mm |
| Accessories |
|
| Warranty | 1 Year |
| Note | *** Features, Price, Specifications are subject to change without notice. |
