DeepCool PQ1000M 80 Plus Gold SMPS
- PQ1000M 80 PLUS Gold Modular Power Supply delivers high efficiency and stability for performance PC systems needing ultra-quiet operation with silent fan modes.
- MTBF : 100,000 Hours ; ATX12V V2.4 ; Hold Up Time : ≥16ms (80% load)) ‘ Input Voltage : 100V – 230V
- ATX 24-Pin Connectors- 1, EPS 4+4 Pin Connectors-2, PCIe (6+2)- 3, SATA Connectors- 10, Peripheral 4-Pin Connectors-5
- Fan Size : 120mm ; Operation Temperature : 0 – 40 °C
₹11,600.00
Out of stock
Email when stock available
DeepCool PQ1000M 80 Plus Gold SMPS
Introducing a new generation of power reliability, the DeepCool PQ-M Series PQ1000M 80 PLUS Gold Modular Power Supply delivers high efficiency and stability for performance PC systems needing ultra-quiet operation with silent fan modes.
Features:
Introducing a new generation of power reliability, the DeepCool PQ-M Series 80 PLUS Gold Modular Power Supply delivers high efficiency and stability for performance PC systems needing ultra-quiet operation with silent fan modes.
Built Solid
Carefully constructed throughout with quality components to ensure pristine power output quality. The modular board is hard connected to the circuit platform instead of traditional cables for added rigidity and less signal noise.
Silence is Golden
A fine-tuned silent fan curve helps produce a perfect balance between cooling and silence, with an additional fan stop option during low temperature conditions. A rear fan control button also allows the option for setting a minimum fan speed when fanless mode is not preferred.
– Optimized thermal performance
– Reduced noise levels overall
– Longer lasting lifespan
| Type | ATX12V V2.4 |
| Product Dimensions | 150×140×86mm (W x L x H) |
| 80PLUS Certifications | GOLD |
| Fan Size | 120mm |
| Fan Bearing | FDB |
| Topology | Active PFC + Full Bridge SRC LLC + DC to DC |
| Capacitors | Full Japan Electrolytic Capacitors |
| Power Good Signal | 100-500ms |
| Hold Up Time | ≥16ms (80% load)) |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP |
| Operation Temperature | 0 - 40 °C |
| Regulatory | CCC/CE/FCC/TUV-SUD/cTUVus/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/UKCA |
| Erp Regulation | ErP 2013 |
| MTBF | 100,000 Hours |
| Warranty | 10 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
| Brands | |
|---|---|
| Product Type | |
| Modular | |
| Wattage | |
| PSU Certification | |
| EAN / UPC Code | |
| Warranty |
