Number of keys: 68
FN key multifunctional
Product size: 313.70 × 119.86 × 40.35 ± 0.1 mm (excluding side panels)
Product size: 322.40 × 119.86 × 40.35 ± 0.1 mm (including side panels)
Product weight approximately: 799 g (excluding wire)
Package Dimension: 354 x 162 x 57 mm
Package Weight: 1100g
Rated voltage: DC 5V
Rated current: ≤500 mA
The HERO 68HE supports adjustable magnetic switch actuation from 0.1 mm to 3.4 mm. You can fine-tune the Rapid Trigger adjustment with accuracy down to 0.01 mm.
The keyboard also supports compatible magnetic switches, allowing you to customize the switch feel. In addition, the removable keycaps make it easy to personalize the keyboard with compatible aftermarket keycaps.
The keyboard is designed for extremely fast input response.
As a result, the keyboard can register inputs quickly during fast-paced gaming.
The HERO 68HE driver provides several advanced gaming functions.
Dynamic Keystroke (DKS): Assign up to four functions to one key depending on how deeply you press or release it.
Multi-Point Trigger (MPT): Assign three different functions to a single key at different actuation depths.
Mod Tap (MT): Use one key for two actions. A tap can perform one function, while holding the key performs another.
Toggle Function (TGL): Configure a key to trigger continuously when activated or operate normally when held.
Release Trigger (END): Assign an additional function that activates when you release a key.
SOCD: Bind two directional keys so that the latest input takes priority and automatically releases the previous input.
Rapid Trigger (RT): Dynamically adjusts the trigger and reset points based on your key movement for faster repeated inputs.
The driver allows you to view magnetic switch travel and magnetic flux in real time. You can also calibrate each switch directly through the software.
During calibration, press each key until it is detected correctly. Once all keys are calibrated, save the settings for consistent magnetic switch performance.
The driver also supports a 0 dead-zone setting for greater switch accuracy.
The HERO 68HE uses a wired USB Type-C connection for reliable and stable performance. This makes it suitable for competitive gaming where consistent input response is important.
The software allows you to adjust several keyboard settings, including magnetic switch behavior and sleep time. The default sleep timer is approximately 3 minutes, and users can change or disable it through the driver.
Warranty: 1 year warranty from the date of purchase only for manufacturing defects.
Important: Please note that listing color will not match 100% from the physical product color.
| Model Number | HERO68WM |
| Connection | Wired USB Type-C |
| Number of Keys | 68 Keys |
| Keycaps | Side-Printed PBT (White) |
| Switch Type | Meteor Magnetic Switch (Hot-swappable) |
| Polling Rate | 8000 Hz |
| Scanning Rate | Up to 128,000 Hz (Single Key) |
| Dimensions | 322.40 × 119.86 × 40.35 mm (including side panels) |
| Weight | ~799g (excluding cable) |
| Voltage/Current | DC 5V / ≤500 mA |
| System Support | Windows XP, 7, 8, 10, 11 |
| WARRANTY | 1 Year |
