Asus Prime AP303 TG ATX Mid Tower Case

Asus Prime AP303 TG ATX Mid Tower Case

Feature

The Asus Prime AP303 is a compact 44-liter ATX case with support for graphics cards up to 360mm long, 360mm radiators up to 60mm thick, and ATX PSUs up to 180mm long.

• Compact Size with Maximal Capacity: 44-liter footprint supports up to 360mm graphics cards, up to 360mm radiators (60mm max thickness), up to 180mm ATX PSUs
• Enhanced Rigidity for Graphics Cards: Added bracket supports GeForce RTX 50 Series graphics cards from 310mm to 360mm long, reducing sagging and movement
• Power Cable for High-End Systems: UL-certified power cable delivers 15 amps to ensure stable operation
• Optimized for Cooling: Support for up to 360mm radiators and up to seven fans handles any thermal scenario
• Front Panel USB Type-C Support: A 20Gbps USB Type-C port enables high-speed data transfer speeds
• Structural Graphics Card Bracket
• Compact ATX Case with Max. Capacity

Compact Frame. Massive Potential. The ASUS Prime AP303 is a compact 44-liter ATX chassis that accommodates 360mm radiators up to 60mm thick and graphics cards up to 360mm long. It features a graphics card bracket and holder to keep cards firmly mounted, plus an internal power cable that delivers 15 amperes to maintain stable power delivery for high-end PC builds. Exceptional Space Efficiency The AP303 is designed to maximize internal space, enabling installation of graphics cards up to 360mm long, radiators up to 360mm long and ATX power supplies up to 180mm long

• 60mm clearance for thicker radiators and fans to enhance cooling
• Support for up to 1200-watt ATX power supplies (up to 180mm long)

Superior Stability Under Heavy Loads Alongside the graphics card holder is a graphics card bracket that supports GeForce RTX 50 Series graphics cards from 310mm to 360mm long. It securely mounts the graphics card with screws, reducing sagging and movement. Efficient Cooling With support for up to 360mm radiators and up to seven fans, the AP303 is primed to deal with the thermal scenarios of high-performance hardware. Quasi-Filter Mesh Panels Metallic quasi-filter mesh panels are designed to enhance airflow and minimize dust ingress, delivering both performance and protection in a sleek style. Pioneering Cable for High-End Systems The UL-certified internal power cable delivers 15 amperes of current to ensure stable operation for high-end systems with a 1200W power supply. USB Type-C Support AP303 includes one 20Gbps Type-C port and two USB 3.0 ports for future-ready and backward-compatible connectivity. Unified Front I/O Header A thoughtful header design makes connecting Front Input/Output (FIO) components to the motherboard easy. Organized Cabling A 34mm-wide compartment behind the motherboard provides ample space to neatly organize cables, despite the relatively compact dimensions of the chassis. Tool-Free Side Panels The side panels of the AP303 use a simple but secure clip mechanism to attach to the case. This makes them easy to remove, providing easy access to the interior of the chassis. Cooling Support (Top)

• 3 x 120 mm
• 3 x 140 mm

Cooling Support (Rear)

• 1 x 120 mm

Pre-installed Fans (Rear)

• 1 x 120 mm
