Arctic P14 Pro PST 140mm White Cabinet Fan

Arctic P14 Pro PST 140mm White Cabinet Fan

Feature

The high static pressure makes the Pro fans ideal for use on radiators as they can effectively move the air through tight obstacles. Pressure-optimized fans are also particularly suitable for pinhole covers or mesh fabrics that generate additional resistance.

Maximum Power, Redefined

Revised fan blade design for an optimal balance of performance and smoothness.

PST - Proven Cable Management

Thanks to the additional PWM socket, the P14 Pro PST CO can be connected directly to other fans. This means that several fans can be connected in series and controlled synchronously via a single connection.

SOTA Microcontroller

Reduces motor noise and automatically compensates for speed drops with increased resistance. Integrated protection mechanisms limit inrush current peaks and reliably protect against damage caused by reverse polarity.

Minimum gap dimensions for maximum efficiency

Lower manufacturing tolerances and gap dimensions allow the fan to work more effectively against drag, maximizing static pressure and airflow efficiency.

More Power - Less Volume

The fan impresses with a significant increase in performance even in the low speed range. Normalized to 25 dB (A), the fan offers both higher air flow and increased static pressure – ideal for quiet and powerful cooling.

Fan Specifications:

• Fan Speed: 400–2500 rpm, PWM controlled 0 rpm below 5 % PWM
• Airflow: 110 cfm | 186 m³/h
• Static Pressure: 5.2 mmH2O
• Fan Bearing: Fluid Dynamic Bearing
• Typical Voltage: 12 V DC
• Start Up Voltage: 5 V DC
• Current: 0.35 A
• Cable Length: 400 mm + 80 mm Daisy-Chain Cable
• Connector: 4-Pin Fan Plug + 4-Pin Socket

General Specifications:

• Operating Ambient Temperature: 0–40 °C
• Dimensions: 140 (L) x 140 (W) x 27 (H) mm
• Net Weight: 242 g
