* Select motherboards may require BIOS update based on date of manufacture or purchase.
1. The information contained herein is for informational purposes only, and is subject to change without notice. Timelines, roadmaps, and/or product release dates shown herein are plans only and subject to change. "Zen 3" is a codename for AMD architectures, and are not product names. GD-122.
2. Max boost for AMD Ryzen processors is the maximum frequency achievable by a single core on the processor running a bursty single-threaded workload. Max boost will vary based on several factors, including, but not limited to: thermal paste; system cooling; motherboard design and BIOS; the latest AMD chipset driver; and the latest OS updates. GD-150.
3. Precision Boost Overdrive requires an AMD Ryzen Threadripper or a Ryzen 3000/4000/5000 series desktop processor, and a compatible motherboard. AMD Ryzen 3400G and 3200G series processors are not compatible. Because Precision Boost Overdrive enables operation of the processor outside of AMD’s published specifications, use of the feature invalidates the AMD product warranty and may also void warranties offered by the system manufacturer or retailer. Availability of Precision Boost Overdrive in pre-built OEM desktop systems will vary based on the PC manufacturer’s settings. Check with the PC manufacturer prior to purchase. GD-179.
4. Testing as of Dec 2023 by AMD Performance Labs on a test system configured with a Ryzen 7 5700X3D, Nvidia GeForce GTX 4080 graphics, Gigabyte X570S Aorus Master motherboard, 32GB 6400MHz RAM (2x16GB), Samsung 980 Pro 1TB NVMe, and Windows 11 Pro vs. A similarly configured system with an Intel Core i5-13600KF, Nvidia GeForce GTX 4080 graphics, ROG Strix Z790-E Gaming Wifi motherboard, 32GB 6400MHz RAM (2x16GB), Samsung 980 Pro 1TB NVMe, and Windows 11 Pro on the following titles at 1080p, VBS enabled, high details: Control, Naraka: Bladepoint, World of Tanks, Watch Dogs: Legion, Call of Duty: Modern Warfare, Red Dead Redemption 2, Rainbow Six Seige, Shadow of the Tomb Raider, Mount & Blade 2, DOTA2, PUBG, Dying Light 2. System manufacturers may vary configurations, yielding different results. R5K-128.
© 2024 Advanced Micro Devices, Inc. All rights reserved. AMD, the AMD Arrow logo, Ryzen, Radeon, and combinations thereof are trademarks of Advanced Micro Devices, Inc. Other product names used in this publication are for identification purposes only and may be trademarks of their respective companies. PID# 242734650-A
AMD
16
730143316552
4.8 GHz
Ryzen 9 5900XT
Ryzen 9
Normal
AM4
Silver
N/A
100-100001581WOF
1 kg
N/A
| General Specifications | |
| Name | AMD Ryzen™ 9 5900XT |
| Family | Ryzen |
| Series | Ryzen 5000 Series |
| Form Factor | Boxed Processor , Desktops |
| Market Segment | Enthusiast Desktop |
| Consumer Use | Yes |
| Commercial Use | No |
| Regional Availability | Global |
| Former Codename | Vermeer |
| Architecture | Zen 3 |
| # of CPU Cores | 16 |
| Multithreading (SMT) | Yes |
| # of Threads | 32 |
| Max. Boost Clock | Up to 4.8 GHz |
| Base Clock | 3.3 GHz |
| L1 Cache | 1024 KB |
| L2 Cache | 8 MB |
| L3 Cache | 64 MB |
| Default TDP | 105W |
| Processor Technology for CPU Cores | TSMC 7nm FinFET |
| Processor Technology for I/O Die | 12nm (Globalfoundries) |
| CPU Compute Die (CCD) Size | 74mm² |
| I/O Die (IOD) Size | 125mm² |
| Package Die Count | 3 |
| Unlocked for Overclocking | Yes |
| CPU Socket | AM4 |
| Supporting Chipsets | X570 , B550 , A520 , X470 , B450 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES , AMD-V , AVX , AVX2 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 |
| Thermal Solution (PIB) | Not Included |
| Max. Operating Temperature (Tjmax) | 90°C |
| *OS Support | Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit |
| Connectivity | |
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
| Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
| Native USB 2.0 (480Mbps) Ports | 0 |
| Native SATA Ports | 2 |
| PCI Express® Version | PCIe® 4.0 |
| Native PCIe® Lanes (Total/Usable) | 24 , 20 |
| Additional Usable PCIe Lanes from Motherboard | amd_x570 16x Gen 4 amd_x470 2x Gen 3, 8x Gen 2 |
| NVMe Support | Boot , RAID0 , RAID1 , RAID10 |
| System Memory Type | DDR4 |
| Memory Channels | 2 |
| Max. Memory | 128 GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed | 2x1R DDR4-3200 2x1R DDR4-3200 4x1R DDR4-2933 4x2R DDR4-2667 |
| ECC Support | Yes (Requires mobo support) |
| Graphics Capabilities | |
| Graphics Model | Discrete Graphics Card Required |
| Key Features | |
| Supported Technologies | AMD Zen 3 Core Architecture , AMD StoreMI Technology , AMD Ryzen™ Master Utility , AMD Ryzen™ VR-Ready Premium |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
