Zotac ZBOX Magnus One ECM73070C Mini Gaming PC
- 8.3 liter compact chassis
- 10th Gen Intel Core i7 processor
- ZOTAC GAMING GeForce RTX 3070 8GB GDDR6
- Up to 64GB DDR4-2933/2666 memory support
₹138,199.00
Out of stock
Email when stock available
Zotac ZBOX Magnus One ECM73070C Mini Gaming PC
Features
POWER INSPIRED
The MAGNUS ONE is the ultimate ZBOX Mini PC built for hardware enthusiasts. The ultimate performance comes from an Intel Core processor and a ZOTAC GAMING GEFORCE RTX 30 series graphics card powered by the NVIDIA Ampere architecture. MAGNUS ONE has been designed to be the one system that can be your daily computer, the office workstation, the system for creating, or the system for gaming.Experience faster performance over previous-generation GPUs and take in the life-like and smooth visuals with the 2nd generation RT cores and Tensor cores.Connect wirelessly with the latest WiFi 6, pair devices using the latest Bluetooth 5, or plug into either the fast Gigabit Ethernet or faster Killer 2.5Gbps Ethernet port.
|
|
|
|
|
|---|---|---|---|
RESPONSIVE PROCESSINGThe MAGNUS ONE is more powerful than ever with performance on par with even some desktops many times the size. Equipped with a multi-core Intel Core i7-10700 processor, expect responsive processing. |
INTEGRATED POWERThe MAGNUS ONE includes an internal 500W 80+ Platinum power supply. Among power supplies, Platinum is the highest rated option for its effective power use efficiency. |
UPGRADING THE MAGNUS ONEEasy with quick access to internal components. Unlock two screws at the rear, and simply remove the top lid and side panels to gain access to the internals to upgrade the SO-DIMM memory, Optane Memory, M.2 SSD, or 2.5” HDD/SSD. |
THE FAST LANE
|
Product description
Empower everything in one incredibly powerful, versatile Mini PC. MAGNUS ONE boasts the ultimate performance in an all-new and compact design. It is the first Mini PC taking advantage of the ZOTAC GAMING GeForce RTX 3070 graphics card for high-fidelity ray-traced graphics and cutting-edge AI features with DLSS. Paired with a 10th Gen Intel Core i7 processor, upgradable memory and storage support, full-range connectivity options with Killer networking, MAGNUS ONE has the do-it-all capability to deliver the best experience for daily tasks, gaming, entertainment, content creation and business.
Empower everything in one incredibly powerful, versatile Mini PC. ZBOX Magnus One (Barebone) boasts the ultimate performance in an all-new and compact design. It is the first Mini PC taking advantage of the ZOTAC GAMING GeForce RTX™ 3070 graphics card for high-fidelity ray-traced graphics and cutting-edge AI features with DLSS. Paired with a 10th Gen Intel® Core™ i7 processor, upgradable memory and storage support, full-range connectivity options with Killer networking, MAGNUS ONE has the do-it-all capability to deliver the best experience for daily tasks, gaming, entertainment, content creation and business.
- 8.3 liter compact chassis
- 10th Gen Intel Core i7 processor
- ZOTAC GAMING GeForce RTX 3070 8GB GDDR6
- Up to 64GB DDR4-2933/2666 memory support
- 1 x HDMI 2.1, 3 x DisplayPort 1.4a, 1 x HDMI 1.4 (integrated)
- 4 x USB 3.1 GEN2, 4 x USB 3.0 (1 Type-C)
- Killer WiFi, Gigabit and 2.5Gbps Ethernet
- 500W 80+ Platinum power supply
- Creator Ready / 4K Ready / Gaming Ready / VR Ready
| Computing System | |
| Processor | Intel Core i5-10400 (6-core 2.9 GHz, up to 4.3 GHz) |
| Chipset | Intel, NVIDIA |
| Graphics | |
| Graphics Engine | ZOTAC GAMING GeForce RTX 3060 12GB GDDR6 192-bit |
| Video Output | 1 x HDMI 1.4 (up to 3840x2160@30Hz) (integrated) 1 x HDMI 2.1* (up to 7680x4320@60Hz) 3 x DisplayPort 1.4a (up to 7680x4320@60Hz) Up to Quad Display Support *Ultra High Speed HDMI Cable is required to support 8K/60FPS or 4K/120FPS |
| Storage | |
| Hard Drive | 1 x 2.5-inch SATA 6.0 Gbps HDD/SSD bay |
| Mass Storage | N/A |
| Optical Drive | N/A |
| mSATA | N/A |
| M.2 | 1 x M.2 PCIe x4 / SATA SSD slot (2242,2280), 1 x M.2 PCIe x4 SSD / Intel Optane memory slot (2242, 2280, 22110) |
| Card Reader | 3-in-1 (SD/SDHC/SDXC) |
| I/O Ports | |
| Audio | Microphone, Headphone, HDMI |
| USB Port | 4 x USB 3.1 4 x USB 3.0 (1 Type-C) |
| LAN | Dual LAN (Gigabit Ethernet, 2.5Gbps Ethernet) |
| Antenna | Dual WiFI SMA connetor |
| Wifi | WiFi 6 AX1650 |
| Bluetooth | Bluetooth 5 |
| Legacy I/O | N/A |
| CIR Infrared Port | N/A |
| Thunderbolt | N/A |
| USB | N/A |
| IDE | N/A |
| VGA | N/A |
| Mechanical | |
| Kensington Lock | Yes |
| LED Indicators | Power, HDD, WiFi |
| Power Supply | 500W 80+ Platinum |
| Cooling system | Fan + Heatsink |
| ZBOX Dimensions |
265.5mm x 126mm x 249mm (10.45in x 4.96in x 9.8in) |
| Case Mounting |
None |
| Miscellaneous | |
| Supported OS |
Windows 10 64-bit |
| Accessories |
2 x WiFi antenna
Power Cord (bundled cable type dependent on region)
Warranty Card
Quick Install Guide
USB drive with O/S driver
Nylon Cable Tie (optional) |
| Warranty |
3+2 Years |
| Note |
***Features, Price and Specifications are subject to change without notice. |
