No reviews yet. Be the first to review!

| Specification | Details |
|---|---|
| Product Collection | Intel® NUC Kit with 10th Generation Intel® Core™ Processors |
| Processor Included | Intel® Core™ i3-10110U Processor (4M Cache, up to 4.10 GHz) |
| Board Number | NUC10i3FNB |
| Supported Operating Systems | Windows 11, 64-bit*, Windows 10, 64-bit* |
| Recommended Customer Price | $322.66-$325.12 |
| Total Cores | 2 |
| Total Threads | 4 |
| Max Turbo Frequency | 4.10 GHz |
| Processor Base Frequency | 2.10 GHz |
| Max Memory Size (dependent on memory type) | 64 GB |
| # of Memory Slots | 2 |
| Memory Types | DDR4-2666 1.2V SO-DIMM |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 42.6 GB/s |
| Internal Drive Form Factor | M.2 and 2.5" Drive |
| # of Internal Drives Supported | 2 |
| Graphics Output | HDMI 2.0b; USB-C (DP1.2) |
| # of Displays Supported | 3 |
| # of Thunderbolt™ Ports | 1x Thunderbolt™ 3 |
| # of USB Ports | 7 |
| USB Configuration | 2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers |
| Total # of SATA Ports | 2 |
| Max # of SATA 6.0 Gb/s Ports | 2 |
| RAID Configuration | 2.5" HDD/SSD + M.2 SATA SSD (RAID-0 RAID-1) |
| Integrated LAN | Intel® Ethernet Connection I219-V |
| Wireless Included | Intel® Wi-Fi 6 AX201 (Gig+) |
| Bluetooth Version | 5.2 |
| TDP | 25 W |
| DC Input Voltage Supported | 19 VDC |
| Chassis Dimensions | 117 x 112 x 51mm |
| Board Form Factor | UCFF (4" x 4") |
| Intel® HD Audio Technology | Yes |
| Intel® Rapid Storage Technology | Yes |
| Intel® Optane™ Memory Supported | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Platform Trust Technology (Intel® PTT) | Yes |
| TPM | No |
| Intel® AES New Instructions | Yes |
