Corsair CX650M 650 Watt 80 Plus Bronze SMPS
- Active PFC with full range AC input (100-240 VAC)
- 120mm thermally controlled rifle bearing fan
- Engineered to meet maximum power output at a 40°C temperature rating.
- Over-voltage protection, under-voltage protection, short circuit protection, over power protection, and over temperature protection provide maximum safety to your critical system components.
- Safety and Agency Approvals: FCC, ICES, CE, UL, cUL, RCM, TÜV, CB, CCC, BSMI, EAC, RoHS, WEEE, KC
₹4,900.00
Email when stock available
Corsair CX650M 650 Watt 80 Plus Bronze SMPS
Features
An ideal choice for value-conscious system builders and upgraders
Corsair CX650M power supply units provide modern power supply technologies and 80 PLUS Bronze efficiency at a competitive price point. It is black with black cable sleeving and connectors and a thermally controlled 120mm fan. The LLC resonant topology with DC to DC ensures complete compatibility with all modern-day PCs.
Good looks
The matte black finish, black-sleeved cables and black connectors help give your system a restrained, high-tech look.
Reliable and compatible
CX650M is built and tested to strict standards for trouble-free installation and smooth operation.
Corsair engineering and quality control
Every Corsair power supply is designed by our California engineering team and built to our exact specifications. The same care that goes into the design and testing of our renowned high-power enthusiast power supplies also goes into the CX Series, because you need confidence and reliability regardless of your build budget.
Ample connectors and long cables
Long cables make CX650M suitable for installation even in full-height tower cases, and the generous cable count allows you to power multiple components and storage devices.
Large-diameter, thermally controlled fan
Once you’ve installed a PSU, you shouldn’t have to think about it. Employing a thermally controlled fan makes the CX Series virtually silent at idle, and the large diameter reduces noise even when you’re pushing your system hard.
COMPACT SIZE
At just 140mm long, the CX-M Series offers great flexibility in build configurations.
Contents and Specifications
Package contents
- CX650M ATX Power Supply
- Power Cord
- x4 Mounting Screws
- Pack of Zip-ties
- Warranty Document
Compatibility
Supports ATX12V 2.4/2.3/2.2/2.01 and EPS12V 2.92 standards
Features
- Active PFC with full range AC input (100-240 VAC)
- 120mm thermally controlled rifle bearing fan
- Engineered to meet maximum power output at a 40°C temperature rating.
- Over-voltage protection, under-voltage protection, short circuit protection, over power protection, and over temperature protection provide maximum safety to your critical system components.
- Safety and Agency Approvals: FCC, ICES, CE, UL, cUL, RCM, TÜV, CB, CCC, BSMI, EAC, RoHS, WEEE, KC
| Weight | 1.5 |
| Adjustable Single/Multi 12V Rail | No |
| ATX Connector | 1 |
| ATX12V Version | v2.4 |
| Continuous power W | 650 Watts |
| Fan bearing technology | Rifle |
| Fan size mm | 120mm |
| MTBF hours | 100,000 hours |
| Multi-GPU ready | NO |
| 80 PLUS Efficiency | Bronze |
| PSU Form Factor | ATX |
| iCUE Compatibility | None |
| Zero RPM Mode | No |
| Cable Type | Low-Profile, All Black |
| EPS12V Connector | 2 |
| EPS12V Version | 2.92 |
| Modular | Semi |
| PCIe Connector | 2 |
| SATA Connector | 6 |
| Warranty | 5 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
| Brands | |
|---|---|
| Modular | |
| PSU Certification | |
| Wattage | |
| EAN / UPC Code |
