HAF 500 is Cooler Master's classic HAF series. The HAF 500's 200mm large intake ARGB fans provide excellent airflow and top performance.
 |  |  |  |
|---|---|---|---|
VERSATILE COOLING OPTIONS
| DUAL 200MM ARGB FANS
| MESH FRONT PANEL
| ROTATABLE GPU FAN
|
 |  |  |  |
|---|---|---|---|
USB 3.2 GEN 2 TYPE C SUPPORT
| SCREWLESS & TOOL-FREE TG SIDE PANEL DESIGN
| REMOVABLE TOP PANEL
| HAF 500
|
Cooler Master
4719512124208
E-ATX
Normal
360mm
Transparent
2 Year
Black
H500-KGNN-S00
1 kg
N/A
| Specification: | |
|---|---|
| Product Name | HAF 500 |
| Product Code | H500-KGNN-S00 |
| Exterior Color | Black |
| Materials | Exterior: Steel, Mesh, Plastic
Left Side Panel: Tempered Glass, Steel |
| Dimensions(L x W x H) | Incl. Protrusions: 516 x 224 x 510mm |
| Motherboard Support | ITX, M-ATX, ATX, SSI CEB, E-ATX* (*up to 12″x14.1″, may impact cable management and case features) |
| Expansion Slots | 7 |
| Drive Bays | 5.25“ ODD: N/A
3.5” / 2.5” Combo: 2 2.5” SSD: 2 |
| I/O Panel | USB Ports: 2 x USB 3.2 Gen 1 (USB 3.0), 1 x USB 3.2 Gen2 type C
Audio In / Out: 1 x single Audio jack Other: ARGB Hub |
| Pre-installed Fan(s) | Front: 2 x 200mm ARGB Fans
Rear: 1 x 120mm SickleFlow PWM ARGB Internal: 1 x 120mm SickleFlow PWM |
| Fan Support | Top: 3 x 120mm / 2 x 140mm / 2 x 200mm
Front: 3 x 120mm / 2 x 140mm / 2 x 200mm *200mm Mounting Hole Spacing 154 x 154 w/ up to 30mm thickness Rear: 1 x 120mm Top on HDD cage: 1 x 120mm |
| Radiator Support | Top: 120 /140/240 /280 /360mm
Front: 120 / 140 / 200 / 240 / 280 / 360mm Rear: 120mm |
| Clearances | CPU Cooler: 167mm / 6.5″
Power Supply: 180mm / 7.1″ Graphics Card: 410mm / 16.1” |
| Cable Routing | Behind MB Tray: 30mm |
| Dust Filters | Top, Bottom |
| Power Supply Support | Bottom mount, ATX |
| Net weight | 9.5kg |
| Gross weight | 11.2kg |
| Carton dimension (L x W x H) | 588 x 315 x 605mm |
| Warranty | 2 Years |
| Note* | Price, feature and specifications are subject to change without notice. |
